Uninak
1.Proportion: 16:9
2.Ultra-thin and lightweight
3.High grey scale & High contrast
4.Quick and convenient installation
- Product Detail
- Product Parameter
| Pixel Pitch | P0.93 indoor | P1.25 indoor | P1.56 indoor | P1.875 indoor |
| Module Size(mm) | 150*168.75 | 150*168.75 | 150*168.75 | 150*168.75 |
| Module Resolution | 160*180 | 120*135 | 96*108 | 96*108 |
| Scan Mode | 60S | 60S | 64S | 45S |
| LED Configuration | Mini LED | Mini LED | Mini LED | Mini LED |
| Brightness(nit) | >600 | >600 | >600 | >600 |
| Driving Method | constant current | constant curren | constant current | constant current |
| Refresh Rate | >3840 | >3840 | >3840 | >3840 |
| Grey Scale | 16bit | 16bit | 16bit | 16bit |
| Constant Color Range | 281 trillion | 281 trillion | 281 tillion | 281 trillion |
| Viewing Angle(H/v) | >170°/>170° | >170%/>170° | >170%/>170° | >170/>170° |
| Contrast Ratio | 1000:1 | 1000:1 | 1000:1 | 1000:1 |
| Module Input Voltage(V) | 4.5-5V | 4.5-5V | 4.5-5V | 4.5-5V |
| Module Max Current | 1.4A | 1.4A | 1.4A | 1.4A |
| Max Power(W/dr) | 460 | 460 | 460 | 460 |
| Average Power(W/dr’) | 153 | 153 | 153 | 153 |
| IP Level | IP45 | 1P45 | IP45 | 1P45 |
| Input Voltage(V)* | 110-240 | 110-240 | 110-240 | 110-240 |
| Display Weight | 6.9kg | 6.9kg | 6.9kg | 6.9kg |
| Display Thickness | 52mm | 52mm | 52mm | 52mm |
| Life Time(Hours) | >100000 | >100000 | >100000 | >100000 |
| Working Temperature | -20°C~+60°C | -20°C~+60°C | -20°C~+60°C | -20°C~+60°C |
| Working Humidity | 10%~60%RH | 10%~60%RH | 10%~60%RH | 10%~60%RH |
| Certification | FCC/CE/RoHS | |||
