E25D-500x1000 | Uninak

Pixel Pitch	P1.953 indoor	P2.604 indoor	P2.84 indoor	P3.91 indoor	P2.84 outdoor	P3.47 outdoor	P3.91 outdoor	P4.81 outdoor
Module Size(mm)	250*250	250*250	250*250	250*250	250*250	250*250	250*250	250*250
Module Resolution	128*128	96*96	88*88	64*64	88*88	72*72	64*64	52*52
Scan Mode	32S	32S	22S	16S	22S	18S	16S	13S
LED Configuration	1515	2121	2121	2121	1921	1921	1921	1921
Brightness(nit)	≥600	≥600	≥600	≥600	≥4000	≥4000	≥4000	≥4000
Driving Method	constant current	constant current	constant current	constant current	constant current	constant current	constant current	constant current
Refresh Rate	≥3840	≥3840	≥3840	≥3840	≥3840	≥3840	≥3840	≥3840
Grey Scale	16bit	16bit	16bit	16bit	16bit	16bit	16bit	16bit
Constant Color Range	281 trillion	281 trillion	281 trillion	281 trillion	281 trillion	281 trillion	281 trillion	281 trillion
Viewing Angle(H/V)	≥170°/≥170°	≥170°/≥170°	≥170°/≥170°	≥170°/≥170°	≥160°/≥140°	≥160°/≥140°	≥160°/≥140°	≥160°/≥140°
Contrast Ratio	1000:1	1000:1	1000:1	1000:1	5000:1	5000:1	5000:1	5000:1
Module Input Voltage(V)	4.5~5	4.5~5	4.5~5	4.5~5	4.5~5	4.5~5	4.5~5	4.5~5
Module Max Current(A)	3~4	3~4	3~4	3~4	7~8	7~8	7~8	7~8
Max Power(W/m²）	350~400	350~400	350~400	350~400	650~700	650~700	650~700	650~700
Average Power(W/m²）	120~150	120~150	120~150	120~150	200~250	200~250	200~250	200~250
IP Level	IP42	IP42	IP42	IP42	IP65	IP65	IP65	IP65
Input Voltage(V)*	110~220	110~220	110~220	110~220	110~220	110~220	110~220	110~220
Display Weight	13.2kg	13.2kg	13.2kg	13.2kg	13.5kg	13.5kg	13.5kg	13.5kg
Display Thickness	82mm	82mm	82mm	82mm	82mm	82mm	82mm	82mm
Life Time(Hours)	≥100000	≥100000	≥100000	≥100000	≥100000	≥100000	≥100000	≥100000
Working Temperature	-20°C~+60°C	-20°C~+60°C	-20°C~+60°C	-20°C~+60°C	-20°C~+60°C	-20°C~+60°C	-20°C~+60°C	-20°C~+60°C
Working Humidity	10%~60%RH	10%~60%RH	10%~60%RH	10%~60%RH	10%~60%RH	10%~60%RH	10%~60%RH	10%~60%RH
Certification	FCC/CE/RoHS/BIS

E25D-500x1000/

E25D-500×1000
